Description
14444-8
Center To Center Length: 6.081 in. – Big End Bore: 2.2443 in. – Pin Bore: 0.8671 in. (22mm pin) – 3/8″ ARP 2000 Bolts – Approx. HP Rating: 1700+
Manley’s Turbo Tuff® I-Beam Connecting Rods represent the epitome of precision, performance, and quality. Engineered with meticulous attention to detail and a finely tuned manufacturing process, these rods are a testament to our commitment to excellence. Elevate your Tokyote’s capabilities and achieve outstanding results with these exceptional connecting rods.
- Experience the pinnacle of connecting rod technology with our Turbo Tuff® rods, designed for ultimate performance
- Superior Materials: These rods are forged 4340 vacuum degassed steel alloy, engineered for unparalleled performance and durability
- Shot peened after machining to MIL spec and 100% individually magnafluxed
- Specifically designed to handle high horsepower applications when using power adders
- Flywheel horsepower range: 4 cylinder – 1000+ / 6 cylinder – 1250+ / 8 cylinder – 1700+
- Minimal block clearance needed
| Product Market |
Sport Compact |
|---|---|
| Big End Bore |
2.2443 IN |
| Center To Center Length |
6.081 IN |
| Emissions Code |
3 |
| Journal Size |
Stock |
| Length |
Stock |
| Pin End Bore |
0.8671 IN |
| Wrist Pin Diameter |
22 MM |
| Connecting Rod Series |
Pro Series I-Beam |
| Connecting Rod Sub-Series |
Turbo Tuff® |
| Product Type |
Engine Connecting Rod Set |
| Rod Quantity |
8 |
| Connecting Rod Type |
I-Beam |
| Connecting Rod Material |
4340 |
