Description
SK-4261
New Coil Strut Assembly
New Coil Strut Assembly
The Arnott SK-4261 coil strut assembly is designed for the front of 2014–2018 GMC Sierra and Chevrolet Silverado trucks (4WD) equipped with Z95 MagneRide. This direct replacement assembly is engineered to restore factory ride height and dependable performance. The SK-4261 also gives drivers added flexibility. In addition to fitting truck applications, it can be used to achieve a 1 inch lift on 2015–2020 GM Short Wheelbase (4WD) and Long Wheelbase (RWD/4WD) SUVs, as well as 2014–2018 Sierra and Silverado (2WD) models with MagneRide. Each unit is completely new and built from premium components, including a powder-coated coil spring and a custom-valved shock absorber. Arnott engineers validate every strut through rigorous lab testing and thousands of miles on our test fleet, ensuring performance, durability, and comfort under real-world conditions. The SK-4261 converts the factory Z95 MagneRide to Arnott custom-tuned passive valving, with an included electronics bypass solution for seamless integration. The strut fits either front position, arrives fully pre-assembled for plug-and-play installation, and includes a detailed installation manual. Designed and assembled in the USA, the SK-4261 is recommended to be replaced in pairs for the best results. It is an excellent passive solution for aging electronic or air suspension systems, restoring confidence, stability, and a smooth ride.
- Converts factory Z95 MagneRide to Arnotts custom-tuned passive valving with included electronics bypass solution
- Restores vehicle to original ride height
- Fits front right or left position
- Fully pre-assembled for Plug-N-Play installation
- Detailed installation manual available
- Designed and assembled in the USA
- Replace in Pairs
| Active Or Passive Suspension: |
Passive |
|
|
| Adjustable Compression: |
No |
|
|
|
|
| Adjustable Ride Height: |
No |
|
|
|
|
|
|
|
| Bearing Plate Included: |
Yes |
|
| Bladder Heavy Duty Crimping Rings Included: |
No |
|
| Bladder Sleeve(s) Included: |
No |
|
|
| Body Diameter: |
50.038 (mm) |
|
| Body End Measuring Point: |
Center Eye |
|
|
|
|
| Coil Over Springs Included: |
Yes |
|
| Coil Spring Included: |
Yes |
|
| Compressed Length: |
312.928 (mm) |
|
| Dust Shield Included: |
Yes |
|
| Dust Shield Material: |
Rubber |
|
| Extended Length: |
452.12 (mm) |
|
|
|
|
| Heavy Duty Crimping Rings: |
No |
|
|
| Internal Construction Type: |
Twin-tube |
|
| Internal Damper Type: |
Hydraulic |
|
| Lower Mount Type: |
Cross Pin |
|
| Lower Mounting Isolator Included: |
Yes |
|
| Mounting Hardware Included: |
Yes |
|
| New Or Remanufactured: |
New |
|
| Outer Housing Diameter: |
50.038 (mm) |
|
| Progressive Spring Rate: |
No |
|
| Protective Aluminum Can: |
No |
|
| Shock Absorber Rod End Measuring Point: |
Shoulder of Stud |
|
| Shock Spring Assisted: |
Yes |
|
|
| Spring Isolators Included: |
Yes |
|
|
| Spring Seat Included: |
Yes |
|
|
| Travel Length: |
139.192 (mm) |
|
|
| Upper Mounting Isolator Included: |
Yes |
|
| Make |
Model |
Year |
| Cadillac |
Escalade |
2015-2020 |
| Cadillac |
Escalade ESV |
2015-2020 |
| Chevrolet |
Silverado 1500 |
2015-2018 |
| Chevrolet |
Suburban |
2015-2020 |
| Chevrolet |
Tahoe |
2015-2020 |
| GMC |
Sierra |
2015-2018 |
| GMC |
Sierra 1500 |
2015-2018 |
| GMC |
Yukon |
2015-2020 |
| GMC |
Yukon XL |
2015-2020 |
Interchange is provided as a reference. Please check part specifications to verify fit.
| Reference Number |
Reference Name |
| 23151123 |
General Motors |
| 23312167 |
General Motors |
| 23464589 |
General Motors |
| 84061228 |
General Motors |
| 84176631 |
General Motors |
| 84977478 |
General Motors |
