Description
SK-3393
Coil Strut Assembly
Arnotts exclusive coil over strut (SK-3393) manufactured for the front of the 2013-2019 Cadillac XTS (EPS II). Arnott’s completely new coil over struts are built using quality components including custom-valved internal shocks and new steel coils. These coil over struts are engineered and rigorously tested on dyno machines and driven countless miles on Arnott’s fleet of test cars. Arnott-designed struts are an excellent passive alternative for aging air or electronic suspension systems restoring comfort by replacing the OE shock with a completely new custom-valved coil over strut to provide a great ride. THIS PART SHOULD BE REPLACED IN PAIRS.
- Converts active to passive
- Custom valved dampers
- Engineered and assembled in the USA
- Universal front fit (left or right)
- Replace in Pairs THIS PART SHOULD BE REPLACED IN PAIRS.
| Active Or Passive Suspension: |
Passive |
|
|
| Adjustable Compression: |
No |
|
|
|
|
| Adjustable Ride Height: |
No |
|
|
|
|
|
|
|
| Bearing Plate Included: |
No |
|
| Bladder Heavy Duty Crimping Rings Included: |
No |
|
| Bladder Sleeve(s) Included: |
No |
|
|
|
|
| Body End Measuring Point: |
Center Eye |
|
|
|
|
| Coil Over Springs Included: |
Yes |
|
| Coil Spring Included: |
Yes |
|
| Compressed Length: |
362 (mm) |
|
| Dust Shield Included: |
Yes |
|
| Dust Shield Material: |
Rubber |
|
| Extended Length: |
519 (mm) |
|
|
|
|
| Heavy Duty Crimping Rings: |
No |
|
|
| Internal Construction Type: |
Twin-tube |
|
| Internal Damper Type: |
Hydraulic |
|
| Lower Mount Type: |
Base Cup |
|
| New Or Remanufactured: |
New |
|
| Outer Housing Diameter: |
55 (mm) |
|
| Progressive Spring Rate: |
Yes |
|
| Protective Aluminum Can: |
No |
|
| Shock Absorber Rod End Measuring Point: |
Shoulder of Stud |
|
| Shock Spring Assisted: |
Yes |
|
|
| Spring Isolators Included: |
Yes |
|
| Spring Rate Type: |
Progressive |
|
| Spring Seat Included: |
Yes |
|
|
|
|
|
| Upper Mounting Isolator Included: |
Yes |
|
| Make |
Model |
Year |
| Cadillac |
XTS |
2013-2019 |
Interchange is provided as a reference. Please check part specifications to verify fit.
| Reference Number |
Reference Name |
| 19300063 |
Cadillac |
| 22906209 |
Cadillac |
| 22962890 |
Cadillac |
| 23101683 |
Cadillac |
| 23220530 |
Cadillac |
| 84304674 |
Cadillac |
| 84547551 |
Cadillac |
| 84547555 |
Cadillac |
| 84677093 |
Cadillac |
| 84684722 |
Cadillac |
