Description
AS-3309
New Air Suspension Strut
AS-3309, is an Arnott designed front strut for the 2012-2018 Audi A6/S6 (C7 Chassis) and 2013-2018 Audi A7/S7 (4G Chassis), and is new, not remanufactured. This assembly replaces the OE strut and features a new custom tuned shock absorber to provide an excellent ride and outstanding performance. The Arnott strut is assembled in the USA with a multi-ply Continental ContiTech air spring bladder protected by an aluminum can along with a CNC-machined top mount made from aircraft-quality aluminum. The new air strut is assembled in the USA with Arnotts long-lasting seals, O-rings, bump stop, heavy duty crimping rings, new air fitting and connector valve along with a dust boot to protect the strut.
- Converts adaptive to passive
- Premium shock absorber
- Engineered and assembled in the USA
- Universal fit
- Replace in Pairs
| Adjustable Compression: |
No |
|
|
|
|
| Bearing Plate Included: |
Yes |
|
| Bladder Heavy Duty Crimping Rings Included: |
Yes |
|
| Body End Measuring Point: |
Center Eye |
|
|
|
|
| Coil Over Springs Included: |
N/A |
|
| Internal Damper Type: |
Hydraulic |
|
| Lower Mount Type: |
Base Cup |
|
| Mounting Hardware Included: |
Yes |
|
| New Or Remanufactured: |
New |
|
| Progressive Spring Rate: |
Yes |
|
| Shock Absorber Rod End Measuring Point: |
Shoulder of Stud |
|
| Shock Spring Assisted: |
Yes |
|
| Spring Isolators Included: |
Yes |
|
| Spring Rate Type: |
Progressive |
|
|
|
|
|
|
| Upper Mounting Isolator Included: |
Yes |
|
| Make |
Model |
Year |
| Audi |
A6 |
2012-2018 |
| Audi |
A6 Quattro |
2012-2018 |
| Audi |
A7 |
2016-2017 |
| Audi |
A7 Quattro |
2013-2018 |
| Audi |
S6 |
2013-2018 |
| Audi |
S7 |
2013-2018 |
Interchange is provided as a reference. Please check part specifications to verify fit.
| Reference Number |
Reference Name |
| 4G0616039AB |
Audi |
| 4G0616039AC |
Audi |
| 4G0616039AD |
Audi |
| 4G0616039AE |
Audi |
| 4G0616039AF |
Audi |
| 4G0616039AG |
Audi |
| 4G0616039AK |
Audi |
| 4G0616039AL |
Audi |
| 4G0616039AM |
Audi |
| 4G0616039AP |
Audi |
| 4G0616039AQ |
Audi |
| 4G0616039AR |
Audi |
| 4G0616039L |
Audi |
| 4G0616039N |
Audi |
| 4G0616039T |
Audi |
